Pico Technology launches the advanced PicoScope 3000E Series PC-based oscilloscopes, now expanded with Mixed-Signal Oscilloscope (MSO) models.
Pico Technology Ltd., a leader in PC-based test & measurement products, is proud to announce the expansion of its renowned PicoScope 3000 series with the introduction of the world’s first USB-powered 5 GS/s oscilloscopes, now available with Mixed-Signal Oscilloscope (MSO) models. Eight models, four with MSO and four without, with bandwidths of 100 MHz, 200 MHz, 350 MHz, and 500 MHz, feature a 5 GS/s sampling rate and 10-bit resolution (up to 14 bits using Enhanced Resolution). These devices set the new standard for next-generation waveform measurement and analysis, offering power, performance, and portability in the field of test and measurement equipment.
The latest additions combine cutting-edge technology with user-friendly design to meet the diverse needs of engineers, technicians and researchers worldwide. These new MSO models offer the same powerful features as the 3000E series, with added digital channel capability, making them ideal for testing and debugging mixed-signal embedded systems. Key features of the new models include:
Bandwidths of 100 MHz, 200 MHz, 350 MHz, and 500 MHz, 5 GS/s sampling rate, and 10-bit resolution: These specifications ensure high-fidelity signal capture across a wide range of applications, from RF communications to power electronics and automotive systems.
Ultra-deep 2 GS capture memory and up to 2 million waveforms per second: Enables capturing long-duration signals at the maximum sampling rate or many closely spaced events, complemented by the PicoScope DeepMeasure™ tool, which provides automatic measurements of waveform parameters on up to a million waveform cycles for each triggered acquisition.
14-bit, 200 MS/s arbitrary waveform generator: Offers real-world waveform generation capabilities for a wide range of applications, eliminating the need for additional external equipment.
USB 3.0 Type-C® connection and power: Ensures high-speed data transfer and compatibility with the latest generation of PCs, simplifying connectivity and setup. An adapter for earlier USB port types is provided.
16 digital channels: MSO models offer 16 digital inputs, allowing engineers to simultaneously capture and analyze both analog and digital signals-ideal for mixed-signal projects such as microcontroller- or FPGA-based systems.
PicoScope 7 user interface for Windows, Mac, and Linux with free updates: Offers a modern, intuitive interface that enhances productivity and workflow efficiency across multiple operating systems.
40 serial decoders included as standard: PicoScope can decode 10BASE-T1S, 1-Wire, ARINC 429, BroadR-Reach, CAN, CAN FD, CAN J1939, CAN XL, DALI, DCC, Differential Manchester, DMX512, Ethernet 10BASE-T, Extended UART, Fast Ethernet 100BASE-TX, FlexRay, I2C, I2S, I3C BASIC v1.0, LIN, Manchester, MIL-STD-1553, MODBUS ASCII, MODBUS RTU, NMEA-0183, Parallel Bus, PMBus, PS/2, PSI5 (Sensor), Quadrature, RS232/UART, SBS Data, SENT Fast, SENT Slow, SENT SPC, SMBus, SPI-MISO/MOSI, SPI-SDIO, USB (1.0/1.1), and Wind Sensor protocol as standard, with more protocols in development and available in the future via free software updates.
Segmented memory, persistence, and fast waveform updates: Enhances waveform visualization and analysis capabilities, enabling users to efficiently extract valuable insights.
Advanced math, measurements, masks, and digital triggering: Provides users with advanced analysis tools for in-depth waveform characterization and interpretation.
Customizable actions: Users can set up automatic actions in response to events during long-duration unattended soak tests.
SDK (Software Development Kit): Allows users to write bespoke applications with the provided drivers for Windows, macOS, and Linux.
Deep memory with unique DeepMeasure™ capability: DeepMeasure provides automatic measurements of a wide range of waveform parameters, such as pulse width, rise time, and voltage, for every individual cycle in the captured waveforms. Up to a million cycles can be analyzed with each triggered acquisition or combined across multiple acquisitions. Results can be easily sorted, analyzed, and correlated with the waveform display, or exported for further analysis.
Trevor Smith, T&M Product Manager at Pico Technology, expressed his excitement: "With the introduction of our two new PicoScope 3000E series oscilloscopes, we're redefining the boundaries of mainstream electronic test and waveform analysis. These instruments enable innovation, precision and limitless possibilities, one waveform at a time."
Patrik Gold, T&M Product Manager at Pico Technology, expressed his enthusiasm: "The introduction of our new MSO models further expands the versatility and capability of our PicoScope 3000E range. Engineers now have the ability to debug mixed-signal systems with greater precision and ease.
