RRC3570-4 Li-Ion Battery (25.20 V, 15.99 Ah, 407.43 Wh)
RRC3570-4 is a standard high-capacity lithium-ion (Li-Ion) battery pack designed to meet power requirements in critical medical and industrial environments. With a nominal voltage of 25.20V and a total energy of 407.43Wh, this device represents a reliable solution for medium-power applications such as hospital beds, ultrasound systems, mobile medical carts, UPS systems, and professional audio equipment. Thanks to the use of latest-generation lithium-ion cells, it guarantees high discharge performance and a long operational life.
The management interface includes SMBus and CAN communication, allowing precise monitoring of the battery status. The design is complemented by an integrated LED indicator for immediate verification of the state of charge (SoC) and state of health (SoH). Designed to withstand demanding use conditions, the battery boasts an IP54 protection rating against dust and water splashes, as well as numerous redundant safety features that prevent overcharging, deep discharge, and overheating. The optimization of the charging profile according to JEITA standards ensures an optimal product lifecycle.
Main Features:
- Electrical Parameters: Nominal voltage of 25.20V and capacity of 15.99Ah.
- Lifespan and Cycles: Maintains 80% of initial capacity after 1,000 charge cycles.
- Protection: IP54 protection rating and mechanical shock-resistant casing.
- Communication: Smart Battery interface compliant with SMBus (SBS) and CANopen implementation (CIA418).
- Safety: Integrated protections against overcurrent, overvoltage, undervoltage, and short circuit.
- International Standards: Worldwide certifications for safety standards (IEC62133-2, UL2054, CE, FCC, UN38.3, and others).
Technical Data:
- Dimensions: 188.50 mm (L) x 85.00 mm (W) x 81.50 mm (H).
- Weight: Approx. 2.08 kg.
- Operating Temperature: 0°C to 45°C during charge; -20°C to 60°C during discharge.
- Charge Current: 8.00A (maximum).
- Discharge Current: 30.00A (continuous); 48.00A (peak).
