SIGLENT SDS2302X Super Phoshor Oscilloscope 300MHz 2 channels
SIGLENT SDS2302X Super Phoshor Oscilloscope 300MHz 2 channels
Standard Accessories:
1 x USB cable
2 x Passibe Voltage Probe
1 x Power Cord
1 x CD documentation and user manual
1 x Quick start guide
1 x Certificate of Calibration
Key Features:
- 70 MHz, 100 MHz, 200 MHz, 300 MHz models
- Real-time sampling rate up to 2 GSa/s
- New generation of SPO technology
• Waveform capture rate up to 140,000 wfm/s (normal mode), and 500,000 wfm/s (sequence mode)
• Supports 256-level intensity grading and color temperature display
• Record length up to 140 Mpts
• Digital trigger system
- Intelligent trigger: Edge, Slope, Pulse, Window, Runt, Interval, Dropout, Pattern and Video (HDTV supported)
- Serial bus triggering and decoder, supports protocols IIC, SPI, UART, RS232, CAN and LIN (Optional)
- Low background noise, supports 1 mV/div to 10 V/div voltage scales
- 10 types of one-button shortcuts, including Auto Setup, Default, Cursors, Measure, Roll, History, Display/Persist, Clear Sweeps, Zoom and Print
- Segmented acquisition (Sequence) mode divides the maximum record length into multiple segments (up to 80,000), according to trigger conditions set by the user. The resulting acquisition has a very small dead time segment.
- History waveform record (History) function, the maximumr ecorded waveform length is 80,000 frames
- Automatic measurement function on 37 parameters, supports statistics, Gating measurements, Math measurements, History measurements and Ref measurements
- Math function (FFT, addition, subtraction, multiplication, division, integration, differential, square root)
- High Speed hardware based Pass/ Fail function
- 16 Digital channels (MSO option), Maximum waveform capture rate up to 500 MSa/s, Record length up to 140 Mpt/CH
- 25 MHz function/arbitrary waveform generator, built-in 10 types of waveforms (option)
- Large 8 inch TFT-LCD display with 800 * 480 resolution
- Multiple interfaces: USB Host, USB Device (USBTMC), LAN (VXI-11), Pass/Fail, Trigger Out, GPIB (optional)
- Supports SCPI remote control commands
- Supports Multi-language display and embedded online Help
| Model | SDS2072/74X | SDS2102/04X | SDS2202/04X | SDS2302/04X |
| Bandwidth | 70 MHz | 100 MHz | 200 MHz | 300 MHz |
| Sampling Rate (Max.) | 2 GSa/s | |||
| Channels | 2/4 + EXT | |||
| Memory Depth (Max.) | ||||
| 140 Mpts (Single-Channel), 70 Mpts (Dual-Channel) | ||||
|
Waveform Capture Rate (Max.) |
140,000 Wfm/s (normal mode), 500,000 (sequence mode) | |||
| Trigger Type | Edge, Slope, Pulse width, Window, Runt, Interval, Dropout, Pattern, Video | |||
| Serial Trigger | IIC, SPI, UART/RS232, CAN, LIN | |||
| Decoder Type (Optional) | IIC, SPI, UART/RS232, CAN, LIN | |||
|
16 Digital Channels (MSO Option) |
Maximum waveform capture rate up to 500 MSa/s, Record length up to 140 Mpts/CH | |||
|
Waveform Generator (Optional) |
Single channel, Max. frequency up to 25MHz, 125MSa/s sampling rate, 16Kpts wave length | |||
| I/O | USB Host, USB Device, LAN, Pass/Fail, Trigger Out, GPIB (Optional) | |||
| Probe (Std) |
PB470 70MHz 1 pcs for each channel |
PP510 100MHz 1 pcs for each channel |
SP2030A 300MHz 1 pcs for each channel |
SP2030A 300MHz 1 pcs for each channel |
| Display | 8 inch TFT LCD (800x480) | |||
