Elektro Automatik ELR 10060-1000 4U 30kW 60V electronic load with energy recovery
Discontinued model, click here to view the new series
Elektro Automatik ELR 10060-1000 4U programmable electronic DC loads with energy recovery. Adjustable from: 0-30kW , 0-60V , 0-1000A , 0.003-5Ω. It has an efficiency of 94% and an approximate weight of 50 kg (110 lbs).
Elektro Automatik EA-ELR 10000 Main Specifications:
- Wide range 342-528 V AC supply for operation on 380 V, 400 V or 480 V grids
- US 208 V models available
- Energy recovery with high efficiency
- DC input galvanically isolated from AC
- Input power rating: 30 kW (15 kW*) per unit, expandable to 1920 kW
- Input voltages: 60 V up to 2000 V
- Input currents: 40 A up to 1000 A per unit
- FPGA based digital control circuit
- Multilingual 5" TFT touch panel
- User profiles, function generator
- Galvanically isolated interfaces (USB, Ethernet, analog) built in
- Master-slave bus for parallel connection
- Extra front USB port for autonomous data recording to USB sticks
- Optional, digital, plug & play interfaces
- SCPI and ModBus RTU/TCP command set
- LabView VIs and remote control software (Windows)
General
This 2019 released series of electronic DC loads with energy recovery, called EA-ELR 10000, is an advancement of the series EA-ELR 9000 HP. It offers 30 kW of continuous power in an enclosure of only 4 height units. Compared to a 30 kW system built from EA-ELR 9000 HP 15 kW models, the devices of this new series save a space of 2U or one third. The extended master-slave bus allows for a connection of up to 64 units in parallel, making it possible to build system with a total power of up to 1920 kilowatts.
The energy recovery function converts the supplied DC energy into a synchronous sine current and feeds it back into the local grid, eliminating the usual heat dissipation to a minimum and saving energy costs at the same time. The large color TFT touch panel offers a different and intuitive kind of manual operation, compared to electronic load series of other manufacturers.
Power ratings, voltages, currents
The available voltage range portfolio goes from models with 0-60 V DC up to models with 0-2000 V DC. Input currents up to 1000 A with only one unit are available. The series offers one power classes with 0-30 kW (standard models) or 0-15 kW (US 208 V models) in only 4U for single devices, which can be extended up to 1080 kW in rack systems for a significantly higher total current.
