TekBox TBTP5, Glass fiber tripod for antennas
TekBox TBTP5 is a glass fiber tripod developed for the stable support of antennas and measuring equipment in EMC laboratories and RF environments. Its lightweight yet sturdy construction allows for quick height adjustment up to 1720 mm with stable footing. Includes a dual 1/4”–3/8” thread, suitable for a variety of antenna setups. Easy to carry thanks to its compact and lightweight design.
- Material: Glass fiber
- Storage height: 1000 mm
- Maximum height: 1720 mm
- Shaft diameter: 30 mm
- Bubble level: No
- Net weight: 6.2 kg
- Max load: 16 kg
- Number of adjustable sections: 1
- Dual thread: 1/4” - 3/8”
TRIPODS
| Product | TBTP1 | TBTP2 | TBTP3 | TBTP4 | TBTP5 |
| Material | Carbon fiber | ABS | Beech wood | Beech wood | Fiberglass |
| Folded height [mm] | 370 | 70 | 850 | 1000 | 1000 |
| Maximum height [mm] | 1490 | 90 | 1800 | 2050 | 1720 |
| Pole diameter [mm] | N/A | N/A | 25 | 30 | 30 |
| Bubble level | YES | NO | YES | YES | NO |
| Net weight (kg) | 1.37 | 0.083 | 3.4 | 5.3 | 6.2 |
| Maximum load (kg) | 6 | 1.4 | 8 | 15 | 16 |
| Number of adjustable sections | 4 | 1 | 2 | 2 | 1 |
